Description
- 15x - 220x OPTICAL magnification, 1280 x 1024 1.3MP image resolution, 30 FPS (video)
- Measurements can be performed in different units (inch/mil/mm/um) and types including straight lines, circles, angles, arches grids and more.
- Polarization can be switched on/off or can be adjusted to offer full or half polarization for controlling glare.
- Discontinued - look up model# AF4915ZT for the replacement.
- SOFTWARE included offers rich features for saving, annotating, comparison, and analysis of captured images. Supports Windows (XP/Vista/7/8/10), Mac OS 10.5 and above, Android, iOS (requires WF-10 wi-fi adapter).
The AM4815ZT combines a polarizer with image processing features; Extended Depth of Field (ED) and Extended Dynamic Range EDR.
EDOF and EDR are available to Windows PC users only.
AM4815ZT's EDOF capture mode can take several pictures at different focus and stack them automatically within a click.
Features (KEY)
MicroTouch (MT) - A trigger sensor that provides convenient snapshot ability without disturbing the image by moving a physical button.
Measurement (MS) - Use simple tools to draw lines, shapes, and text annotations on the image. Calibrate and measure dimensions including lines, circles, and angles.
Polarization (PZ) - Built-in adjustable polarizer greatly reduces glare on reflective surfaces.
Interchangeable Cap (IC) - A selection of removeable end caps for different applications.
Extended Depth of Field (ED) - Automatically capture and combine multiple images at different focus levels to produce a final image with greater depth of field.
Package Contents
1 x USB Digital Microscope
1 x Dino Capture Software CD (Also downloadable from the Dino-Lite website.)
1 x Calibration Target to be used for calibrating measurements.
1 x Set of Alternate Front Caps (6pcs.)
Magnification Range: 10x-220x
Lighting: White LED (8)
Resolution: 1280 x 1024
Megapixels: 1.3MP
Frame Rate (max): 30 FPS
Operating System: Windows XP, Vista 7, 8, 10, Mac OS 10.5 and above
Connection Type: USB 2.0
Image Save Formats: BMP, GIF, PNG, JPG, TIF, PNM, TGA Video Save Formats: WMV, FLV, SWF
Applications: Lab Microscope with high depth of field Warranty Period: 2 years
Country of Origin: Taiwan
